With an open front design, our spray to waste powder booths are perfect for small powder applicators. A cost-effective solution, a spray to waste powder booth makes efficient use of shop space and is used for large or small parts. With an open face design and 3-stage filtration air is drawn in through the open front of the spray booth and passes through the booth’s working area into the filtered exhaust plenum. The air is filtered in three times and discharged back into the room.
Panels are constructed from 18-gauge galvanized steel, flanged and CNC punched on 6” centers for structural integrity. Panels are fastened with 5/16-inch bolts with flanged self-locking nuts and are to be sealed with the provided caulk following assembly.
Collector Module Recirculates clean, filtered air into the booth and includes high quality filters. They are factory-assembled, powder coated white mild steel construction with removable powder drawer.
ETL listed (Class 1 Division 2) and are supplied with multi voltage ballasts to accept any voltage between 120V and 277V power. Bulbs are included.
Interlocked to the exhaust fan and air supply for the spray application equipment.
Effective at catching powder dust; Stage 1: Blanket style filter, Stage 2: Bag style filter, Stage 3: Hepa type filter
Ensures filters are installed and working properly. Interlocks with the air solenoid valve.
This our specialty! You can rest assured that your new equipment will be operational in no time.
The sizes listed below are standard catalog sizes. We can custom build all of our finishing equipment to meet your needs. Call us at 800-637-4027.
| Interior Dimensions | Exterior Dimensions | ||||
| Width | Height | Length | Width | Height | Length |
| 4′ | 7′ | 5′ | 4’4″ | 12′ | 7’8″ |
| 6′ | 7′ | 5′ | 6’4″ | 12′ | 7’8″ |
| 8′ | 7′ | 5′ | 8’4″ | 12′ | 7’8″ |
| 9’8″ | 7′ | 5′ | 10’4″ | 12’6″ | 8’8″ |
| 11’8″ | 7′ | 7′ | 12’4″ | 12’6″ | 11’12” |
| 4′ | 8′ | 5′ | 4’4″ | 12′ | 7’8″ |
| 6′ | 8′ | 5′ | 6’4″ | 12′ | 7’8″ |
| 8′ | 8′ | 5′ | 8’4″ | 12′ | 7’8″ |
| 9’8″ | 8′ | 5′ | 10′ | 12’6″ | 8’8″ |
| 11’8″ | 8′ | 7′ | 12′ | 12’6″ | 11’2″ |
